A.Y. McDonald 8310 Shallow Well Jet Pump 1 HP 230/115V with 30/50 Pressure Switch – 32 GPM Cast Iron Water Pump, 1-1/4 in Inlet, 1 in Outlet – Model 8310

The A.Y. McDonald 8310 Shallow Well Jet Pump is designed to deliver dependable water pressure for residential wells, irrigation systems, and household water supply applications. This pump features a 1 HP motor with dual-voltage capability (230/115V) allowing flexible installation depending on your electrical setup. The pump includes a 30/50 pressure switch that automatically starts and stops the pump based on system pressure, ensuring consistent water pressure for home plumbing systems. Its heavy-duty cast iron housing and seal plate provide durability and corrosion resistance for long service life. The 8300 Series jet pump uses a plastic impeller with stainless steel insert and a stainless steel motor shaft, ensuring efficient performance and reduced wear. With a maximum capacity of up to 32 GPM, the pump is suitable for shallow wells, homes, cabins, and irrigation systems requiring reliable water pressure.

• Model 8310 shallow well jet pump designed for residential well water systems
• 1 HP dual-voltage motor (230/115V) for flexible installation
• Pumps up to 32 gallons per minute (GPM) for strong water delivery
• 30/50 pressure switch for automatic pressure control
• 1-1/4 inch suction inlet and 1 inch discharge outlet for efficient water flow
• Heavy-duty cast iron pump housing and seal plate for durability
• Plastic impeller with stainless steel insert for reliable operation
• Maximum suction lift of about 15 ft for shallow well installations
